Technical specifications
General measurements
Chassis
Brembo braking system
ABS and suspensions
Wheels
Tyres
Engine
Length x width x height
2.170 x 855 x 1.250 mm
Wheelbase
1462 mm
Weight in running order
< 200 kg
Seat height
820 mm
Frame
Mixed aluminium/steel
Swingarm
Alluminium
Front brake
320 mm double disc with monobloc calipers
Rear brake
220 mm single disc with fixed caliper
Front
Fully adjustable inverted fork
Rear
Progressive linkage with shock absorber compressed into swingarm
Front
Alluminum 3,5" x 17"
Rear
5,5" x 17"
Front
120/70-R17
Rear
180/55-R17
Engine type
90° V-twin cylinder
Displacement
749 cc
Bore x stroke
90 mm x 58,9 mm
Lubrification
Dry sump
Crankshaft
Counter-rotating
Maximum power
96 HP / 70,5 kW (A3) 48 hp / 35 kW (A2)
Technical specifications
General measurements
Length x width x height
2.170 x 855 x 1.250 mm
Wheelbase
1462 mm
Weight in running order
< 200 kg
Seat height
820 mm
Chassis
Frame
Mixed aluminium/steel
Swingarm
Alluminium
Brembo braking system
Front brake
320 mm double disc with monobloc calipers
Rear brake
220 mm single disc with fixed caliper
ABS and suspensions
Front
Fully adjustable inverted fork
Rear
Progressive linkage with shock absorber compressed into swingarm
Wheels
Front
Alluminum 3,5" x 17"
Rear
5,5" x 17"
Tyres
Front
120/70-R17
Rear
180/55-R17
Engine
Engine type
90° V-twin cylinder
Displacement
749 cc
Bore x stroke
90 mm x 58,9 mm
Lubrification
Dry sump
Crankshaft
Counter-rotating
Maximum power
96 HP / 70,5 kW (A3) 48 hp / 35 kW (A2)
