Tehnička specifikacija
General measurements
Chassis
Brembo braking system
ABS and suspensions
Wheels
Tyres
Engine
Length x width x height
2310 x 1020 x 1490
Wheelbase
1545 mm
Curb weight
245 kg
Seat height
860mm
Fuel tank
23L
Ground clearance
190mm
Frame
Mixed aluminum/steel
Swingarm
Alluminium
Front brake
Twin 320 mm discs with monoblock calipers
Rear brake
Single 280 mm disc with fixed caliper
Front
Fully adjustable inverted fork, 180 mm wheel travel
Rear
Progressive linkage with single shock absorber, 180 mm wheel travel
ABS
BOSCH cornering
Front
Tubeless spoked rims 3,5x19"
Rear
Tubeless spoked rims 5,0"x17
Front
120/70-R19 Pirelli Scorpion Trail 3, cerchio a raggi 3.5"x19"
Rear
170/60-R17 Pirelli Scorpion Trail 3, cerchio a raggi 5.0"x17"
Engine type
V2 87°, 4 strokes
Displacement
1187cc
Bore x stroke
107 mm x 66 mm
Compression
12.4:1
Max torque
105Nm/ 10.7kgm/ 7000rpm
Max power
92kW/ 125hp/ 9000rpm
Injection system
Magneti Marelli
Max speed
>230Km/h
Cooling system
A liquido
Distribution
DOHC bicilindrico 8 valvole
Emissions
Euro 5+
